Android开发在线音频播放器-第三章核心PlayerService实现

本章深入剖析音频播放器Service的关键实现，通过精选代码片段详解权限配置、播放控制、状态管理等核心功能模块。

播放服务必须声明前台服务权限

name="android.permission.FOREGROUND_SERVICE_MEDIA_PLAYBACK" />
name="android.permission.FOREGROUND_SERVICE" />

1、服务核心变量定义

private static AudioPlayerManager apm; //音频播放管理
private static int mPosSomeTime = 0;// 播放指针 单元
private String jsonList, unit_name; //歌曲列表数据  歌曲名称
private static int bookId; //内层专辑ID
private static String book_name; //内层专辑ID
private static long process = 0; //当前歌曲播放进度
private static long max = 0; //当前歌曲最大进度
private static ExecutorService fixedThreadPool;
private static int isFrom; //来源 0 专辑列表 1首页 2 AI问答
private String book_cover; //专辑封面
private static int bizId; //外层专辑ID
private static String bizTopic; //外层专辑主题
private static long timeStart = 0;   //开始计时的时间戳
private static boolean countDowning = false; //是否倒计时中

2、服务初始化流程

@Override
    public void onCreate() {
        super.onCreate();
        EventBus.getDefault().register(this);
        fixedThreadPool = Executors.newFixedThreadPool(3);
        apm = AudioPlayerManager.getInstance(TbjcPlayerService.this);        Player.Listener listener = new Player.Listener() {
            @Override
            public void onPlayerStateChanged(boolean playWhenReady, int playbackState) {
                switch (playbackState) {
                    case Player.STATE_BUFFERING://加载缓存且还未准备好时触发                        break;
                    case Player.STATE_READY:  //播放准备
                        timeStart = System.currentTimeMillis(); //记录播放开始时间
                        break;
                    case Player.STATE_ENDED: //播放结束时触发
                        process=0;
                        fixedThreadPool.execute(command4); //保存播放进度
                        int sum = 0;
                        sum = ConstantFd.unit_List.size(); //专辑中的歌曲数量
                        if(ConstantFd.loop_type == 2 && sum > 0){ //随机播放
                            int index = (int) (Math. random() * sum-1);
                            to_play(index);
                        }else if(ConstantFd.loop_type == 0){ //顺序播放
                            Log.e("TAG", "mPosSomeTime--->  "+mPosSomeTime);
                            if(mPosSomeTime < sum - 1){//播放指针 小于 列表总数
                                play_next(1); //播放下一个
                            }else { //已播完最后一首  暂停操作
                                ConstantFd.isplay = false;
                                apm.playOrPause(false);
                                PlayStateMsg.sendState(false); //发送播放状态 通知ui
                            }
                        }else if(ConstantFd.loop_type == 1){ //单课循环
                            Log.e("TAG", "单课循环--->  重新开始");
                            playUrl = ConstantFd.unit_List.get(mPosSomeTime).getPlayUrl();
                            apm.setAudioFile2(playUrl); //在线
                            apm.start();
                        }
                        break;
                }            }
        };
        apm.setlistener(listener); //设置播放
        apm.switchSpeed(ConstantFd.speed); //设置播放倍速
        //设置网络
        IntentFilter filter = new IntentFilter(ConnectivityManager.CONNECTIVITY_ACTION);
        if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.TIRAMISU) {
            registerReceiver(networkReceiver, filter, Context.RECEIVER_EXPORTED);
        }else {
            registerReceiver(networkReceiver, filter);
        }
    }

3、数据加载与播放控制

@Override
    public int onStartCommand(Intent intent, int flags, int startId) {
        if (intent != null) {
            book_cover = intent.getStringExtra("book_cover");
            book_name = intent.getStringExtra("book_name");
            bookId = intent.getIntExtra("bookId", 0);
            jsonList = intent.getStringExtra("jsonList");
            isFrom = intent.getIntExtra("isFrom", 0);
            bizId = intent.getIntExtra("bizId", 0);
            unit_name = intent.getStringExtra("unit_name");
            bizTopic = intent.getStringExtra("bizTopic");
            Log.i("TAG", "jsonList : " + jsonList);
        }else {
            Log.e("TAG", "intent null--->  ");
        }
        apm.requestAudioFocus(); //请求音频播放焦点
        if(!TextUtils.isEmpty(jsonList)){ //解析列表数据
            unit_List = new Gson().fromJson(jsonList, new TypeToken>() { }.getType());
            startPlay(); //开始播放
        }else {
            reLoad();
        }
        if (!countDowning) {
            SharedPreferences sharedPreferences = getSharedPreferences(ConstantFd.PREFERENCES, MODE_PRIVATE); //上次定时关闭
            int time = sharedPreferences.getInt(ConstantFd.LastTimeSet, 0);
            if(time > 0){
                showSurplusTime = true; //显示倒计时
                countDown(time * 60 * 1000);
            }else {
                showSurplusTime = false;
            }
        }else {
            ConstantFd.showSurplusTime = true;
            if (ConstantFd.surplusTime > 0) {
                mHandler.removeMessages(2);
                mHandler.sendEmptyMessageDelayed(2, 1000);
            }
        }
        return START_NOT_STICKY;
    }    private void reLoad(){ //加载播放
        isplay = false; //播放状态设为false
        if (!TextUtils.isEmpty(book_name) && bookId >= 0) {
            fixedThreadPool.execute(command1); //使用线程池避免播就了之后卡顿
        }
    }private void countDown(long time) { //设置时间 开始到计时
        Log.i("TAG", "ConstantFd.surplusTime:  "+ConstantFd.surplusTime);
        ConstantFd.surplusTime = time;
        ConstantFd.setTime = time;
        mHandler.removeMessages(2);
        if (ConstantFd.surplusTime > 0) {
            countDowning = true;
            mHandler.sendEmptyMessageDelayed(2, 1000);
        } else {
            countDowning = false;
        }    }

4、播放控制方法实现

//开始播放
private void startPlay(){
        PlayInfoMsg.sendInfo(true); //发送消息 通知UI刷新列表和进度条
        mPosSomeTime = getPoi(unit_name);
        if(apm.isPlaying() && isFrom==1){ //如果是播放中 继续播放，做到从首页跳转过来无缝衔接播放
            PlayShowPoiMsg.sendPoi(mPosSomeTime);
            PlayStateMsg.sendState(true);
        }else {
            if(!TextUtils.isEmpty(unit_name)){ //从列表页传来的单元名称
                PlayUnitPoiMsg.sendPoi(mPosSomeTime, book_cover);
            }else {
                fixedThreadPool.execute(command3); //获取上次播放的单元指针
            }
        }
        Log.i("TAG", "111  isplay:  "+ConstantFd.isplay);
        Log.i("TAG", "111  control_play:  "+ConstantFd.control_play);
        if(!ConstantFd.control_play){ //外面手动暂停 进播放页暂停
            PlayControlTools.setACTION_PAUSE();
        }
    }    private static void setPlayPoi(long poi){ //播放当前歌曲中的指定位置
        apm.getMediaPlayer().seekTo(poi);
    }private void play_next(int LeftorRight) { //播放下一首 0上一个   1下一个
        if(!ConstantFd.hasList()){ //列表无数据
            return;
        }
        int position = mPosSomeTime; //当前单元位置
        if (position == -1) {
            return;
        }
        int sum = 0;
        sum = ConstantFd.unit_List.size();
        if (LeftorRight == 0) { //左
            if (position > 0) {
                position--;
            } else {
                position = sum - 1;
            }
        } else if (LeftorRight == 1) { //右
            if (position < sum - 1) {
                position++;
            } else {
                position = 0;
            }
        }
        to_play(position);    }    private void to_play(int position) { //播放列表中的哪一首歌
        listenUpload();
        mPosSomeTime = position;
        PlayUnitPoiMsg.sendPoi(mPosSomeTime, book_cover); //发送播放指针  并播放
    }

5、消息通信处理机制

@Subscribe(threadMode = ThreadMode.MAIN, sticky = true)
    public void receiveTime(PlayTimeSetMsg msg) { //接收设置的定时时间
        countDown(msg.getTime());
    }    @Subscribe(threadMode = ThreadMode.MAIN, sticky = true)
    public void receiveProcess(PoiToPlayMsg msg) { //接收滑动的进度
        setPlayPoi(msg.getPoi());
    }    @Subscribe(threadMode = ThreadMode.MAIN, sticky = true)
    public void receiveSet(PlaySetMsg msg) { //播放设置倍速
        apm.switchSpeed(ConstantFd.speed);
    }    @Subscribe(threadMode = ThreadMode.MAIN, sticky = true)
    public void receiveEventBus_Poi(PlayUnitPoiMsg msg) { //接收指针 播这一首
        mPosSomeTime = msg.getPoi();
        ConstantFd.isplay = true;
        PlayStateMsg.sendState(true);
        playStart();
    }    @Subscribe(threadMode = ThreadMode.MAIN, sticky = true)
    public void receiveEventBus(PlayControlMsg msg) { //接收消息控制播放
        if (msg.getMsg().equals(PlayControlMsg.YYTS_ACTION_PAUSE)) { //暂停
            playOrPause(false);
            PlayStateMsg.sendState(false); //发送播放状态 通知ui
        } else if (msg.getMsg().equals(PlayControlMsg.YYTS_ACTION_PLAY)) { //播放
            if(apm.getMediaPlayer().getCurrentPosition() >= max){
                setPlayPoi(0);
            }
            playOrPause(true);
            PlayStateMsg.sendState(true); //发送播放状态 通知ui
        } else if (msg.getMsg().equals(PlayControlMsg.YYTS_PLAY_NEXT)) { //下一首
            int sum = 0;
            sum = ConstantFd.unit_List.size();
            if (ConstantFd.loop_type == 2 && sum > 0) { //随机播放
                int index = (int) (Math.random() * sum - 1);
                to_play(index);//播放指定位置歌曲
            } else {
                play_next(1);//播放下一首
            }
        } else if (msg.getMsg().equals(PlayControlMsg.YYTS_PLAY_PREVIOUS)) { //上一首
            int sum = 0;
            sum = ConstantFd.unit_List.size();
            if (ConstantFd.loop_type == 2 && sum > 0) { //随机播放
                int index = (int) (Math.random() * sum - 1);
                to_play(index); //播放指定位置歌曲
            } else {
                play_next(0); //播放上一首
            }
        }
    }

6、线程任务与播放进度管理

private static Handler mHandler = new Handler(new Handler.Callback() { //static  定时
        @Override
        public boolean handleMessage(Message msg) {
            switch (msg.what) {
                case 0: //获取当前进度并发给ui
                    max = apm.getMediaPlayer().getDuration();
                    process = apm.getMediaPlayer().getCurrentPosition();
                    if(max<0){
                        max=0;
                    }
                    PoiToUIMsg.sendMsg(process, max); //发送进度到UI
                    if(ConstantFd.isplay){
                        mHandler.sendEmptyMessageDelayed(0, 1000);
                    }
                    fixedThreadPool.execute(command4); //保存播放进度
                    break;
                case 1:
                    setPlayPoi(msg.arg1);//设置上次进度
                    break;
                case 2: //定时播放 倒计时
                    ConstantFd.surplusTime = ConstantFd.surplusTime - 1000;
                    if (ConstantFd.showSurplusTime) {
                        PlayTimeShowMsg.sendMsg(ConstantFd.surplusTime);
                    }
                    if (ConstantFd.surplusTime > 0) {
                        if(ConstantFd.isplay){
                            mHandler.sendEmptyMessageDelayed(2, 1000); //每秒刷新
                        }
                    } else { //定时播放结束
                        ConstantFd.surplusTime = 0;
                        countDowning = false;
                        if (ConstantFd.setTime != 0) {
                            ConstantFd.isplay = false;
                            apm.playOrPause(false);
                            PlayStateMsg.sendState(false); //发送播放状态 通知ui
                        }
                    }
                    break;
            }
            return true;
        }
    });

private Runnable command1 = new Runnable() {
        @Override
        public void run() { //请求数据 播放列表
            RequestMsg.sendInfo(true);
            getDataList(); //获取播放数据
        }
    };    private Runnable command2 = new Runnable() { //获取上次进度 并保存本次单元指针
        @Override
        public void run() {
            if(!ConstantFd.hasList() || isFrom==2){
                return;
            }
            //获取上次播放进度
            Message msg = new Message();
            msg.what = 1;
            msg.arg1 = (int) getSongProcess();
            mHandler.sendMessage(msg);            //保存播放歌曲指针
                JxwRoom.getInstance().getJxwDatabase().getLastSongDao().deleteAllInfo();
                LastSong song = new LastSong();
                song.setSong_name(ConstantFd.unit_List.get(mPosSomeTime).getShowName());
                song.setIndex(mPosSomeTime);
                song.setBook_id(bookId);
                song.setBook_name(book_name);
                song.setSong_cover(book_cover);
                song.setBiz_id(bizId);
                JxwRoom.getInstance().getJxwDatabase().getLastSongDao().insertInfo(song);
                AlbumSong as =JxwRoom.getInstance().getJxwDatabase().getAlbumSongDao().getSongPoi(book_name, bookId); //保存专辑播放到哪一曲
                if(as!=null){
                    as.setSong_name(ConstantFd.unit_List.get(mPosSomeTime).getShowName());
                    as.setIndex(mPosSomeTime);
                    JxwRoom.getInstance().getJxwDatabase().getAlbumSongDao().updateInfo(as);
                }else {
                    as = new AlbumSong();
                    as.setSong_name(ConstantFd.unit_List.get(mPosSomeTime).getShowName());
                    as.setIndex(mPosSomeTime);
                    as
